What is the purpose of the coupler in the optical splitter
The coupler inside an optical splitter is a passive device that divides or distributes an incoming optical signal into multiple output paths using closely positioned fiber cores or waveguides.
Function of the Coupler
The coupler in an optical splitter serves as the core component that splits the optical signal from a single input fiber into multiple outputs according to a specified splitting ratio, which can be equal or customized for the application . It ensures that the optical power is distributed efficiently to each output port while maintaining signal integrity.
Structure and Working Principle
Most couplers operate based on evanescent wave coupling, where two or more optical fibers or waveguides are brought very close together so that light can transfer from one core to another . In fused biconical taper (FBT) couplers, the fibers are twisted, stretched, and fused, creating a coupling region where the cores are extremely close, allowing controlled light transfer . In planar lightwave circuit (PLC) couplers, lithographically patterned waveguides on a silica chip split the light precisely and uniformly . The coupling region is typically only a few millimeters long, and outside this region, the fibers or waveguides do not interact, ensuring that the signal is only split where intended . The coupler can be designed in various configurations, such as 1×2, 2×2, 1×4, or higher, depending on the number of input and output fibers .
Types of Couplers in Splitters
- Fused Biconical Taper (FBT) Coupler: Uses fused and tapered fibers to split light; commonly used in traditional splitters.
- Planar Lightwave Circuit (PLC) Coupler: Uses waveguides on a silica substrate for precise and uniform splitting; ideal for high-density applications .
Applications
The coupler inside a splitter is essential in FTTx/PON networks, fiber-to-the-home (FTTH) installations, CATV distribution, and optical monitoring systems. It allows a single optical signal to serve multiple endpoints while maintaining the desired power distribution . In summary, the coupler is the key element that enables an optical splitter to divide light efficiently, using either fused fibers or planar waveguides, and its design determines the splitting ratio, insertion loss, and overall performance of the splitter.
